Functional features1. Real and operable starting system, fully display the composition of the automobile starting system.
2. Operate the starting switch, start the motor to work, and truly demonstrate the working process of the car starting system. Through the ammeter and voltmeter on the panel, you can observe the change process of starting current and battery voltage during starting.
3. The panel adopts 4mm thick high-grade aluminum-plastic panel with corrosion resistance, impact resistance, pollution resistance, fire prevention and moisture resistance, and the surface is treated by special process spraying primer; The panel is printed with a color circuit diagram that never fades; Students can visually compare circuit diagrams and physical objects to understand and analyze the working principle of automobile starting system.
4. The total component solution part of the starter is installed on the panel of the teach-in board, which can intuitively understand the composition structure of the starter.
5. The detection terminal is installed on the panel of the teaching board, which can directly detect the electrical signals of each circuit component of the automobile starting system, such as resistance, voltage, current, frequency signal, etc. on the panel.
6. The panel part of the teaching board adopts 1.5mm cold plate stamping forming structure, which has beautiful appearance; the bottom frame part adopts steel structure welding, the surface adopts spraying process treatment, with self-locking caster device, and the base of the teaching board is equipped with a desktop of about 40cm, which is convenient for placing data, light testing instruments, etc.
