| Leveling Range | ±5°(by Electronic Vial Sensor) | |||
| Horizontal Accuracy | ±30" | |||
| Slope(Y-Axis) | ±5° | |||
| Zenith | ±30" | |||
| Vertical Accuracy | ±30" | |||
| Working Radius(with Laser Detector LS-6) | 120m ( w.Detector LS-6) | |||
| Rotating Speed | 120-700rpm | |||
| Operating Duration | Approx.20 Hours(w.Ni-MH Rechargeable Batteries) or 40 Hours(w.regular Alkaline Batteries) | |||
| Remote Control Range | ≤30m(Model RL-1000 w. Alkaline Batteries AAA) | |||
| Scanning Range | 10°~48° | |||
| Laser Source | Laser Diode:635nm,Class Ⅱ:<1mw | |||
| Circular Bubble | 2°/2mm | |||
| Power Supply | Ni-MH Rechargeable Batteries or Alkaline Batteries:Optional | |||
| Operating Temperature | -0°C～+50°C | |||
| Standard Accessories | Laser Detector (w.clamp) LS-6,Remote Control RL-1000,User Manual,Laser Glasses,Laser Target,Universal Adaptor | |||
| Recommended Tripod | Please refer to "Tripods":Aluminum Elevator Tripod(Laser Tripod) | |||
| Packing Details |
1pc per Carton; 7kgs per Carton Size per Carton:0.045CBM(45cm×27cm×36cm) |
|||
| Note | The specifications may be subject to change without prior notice | |||
