ADVANTAGE FEATURES 1) Air-cooled, V-twin cylinder, 4-stroke, DIESEL DRIVEN. 2) Direct injection combustion system. 3) Efficient air cleaner system. 4) Standard electric start. 5) Multi-choice of PTO (power take off) shaft available. |
|||||
| Type | Air Cooled, V-twin Cylinder, 4-Stroke, DIESEL ENGINE | |||||
| Combustion System | Direct Injection | |||||
| Bore x Stroke (mm) | 88 x 75 | 92 x 75 | 95 x 88 | |||
| Displacement (L) | 0.912 | 0.997 | 1.247 | |||
| Compression Ration | 20:01 | |||||
| Engine Speed (RPM) | 3000 | 3600 | 3000 | 3600 | 3000 | 3600 |
| Rated Power (KW) | 13.8 | 14.8 | 14.8 | 16 | 18 | 19 |
| Max. Power (KW) | 15.2 | 16.3 | 16.3 | 17.6 | 20 | 21 |
| Starting System | Electric Start | |||||
| Rotation Direction (View from Flywheel) | Clockwise | |||||
| Fuel Tank Capacity (L) | 12.5L For Options | |||||
| Lub-oil Capacity (L) | 3 | 3.8 | ||||
| Fuel Consumption (g/kw.h) | 250 | 260 | 250 | 260 | 250 | 260 |
| Fuel Type | 0# (Summer), -10# (Winter) Light Diesel Fuel | |||||
| Lub-oil Type | SAE10W30 (CD Grade Above) | |||||
| Dimension (LxWxH)(mm) | 530 x 580 x 530 | 530 x 580 x 530 | 530 x 580 x530 | |||
| Dry Weight (kg) | 68 | 74 | 76 | |||
