| Model | 1WG2.2-36FQ-D | 1WG3.6-60FQ-D | 1WG3.4-75FQ-D | 1WG3.4-85FQ-Z | 1WG4.9-135FC-Z | |
| Engine | Engine Model | LC1P61FA | LC170F-D | G200F | G200F | LC178F/D350F |
| Rated power | 2.7kW | 4.4kW | 4.1 kW | 4.1 kW | 4.9kW | |
| Rated speed | 3600 r/min | 3600 r/min | 3600 r/min | 3600 r/min | 3600 r/min | |
| Displacement | 140CC | 212CC | 196CC | 196CC | 349CC | |
| Fuel tank capcity | 1.0L | 3.0L | 3.6L | 3.6L | 3.5L | |
| Oil capacity | 0.5L | 0.6L | 0.6L | 0.6L | 1.1L | |
| Fuel consumption | ≤30 kg /hm2 | ≤30 kg /hm2 | ≤30 kg /hm2 | ≤30 kg /hm2 | ≤25 kg /hm2 | |
| Tiller | Cutting width | 36cm | 80cm | 85 cm | 85 cm | 135cm |
| Cutting depth | ≥10cm | ≥15 cm | ≥15 cm | ≥18 cm | ≥18 cm | |
| working capacity | 0.1～0.3 m/s | 0.1～0.3 m/s | 0.1～0.3 m/s | 0.1～0.3 m/s | 0.1～0.3 m/s | |
| Efficiency per hour | ≥200m2/h | ≥350m2/h | ≥400m2/h | ≥400m2/h | ≥750m2/h | |
| Transmission | Worm wheel | Chain | Gear/Chain | Gear | Gear | |
| Connecting | Belt | Belt | Belt | Straight | Straight | |
| Rated blade speed | 120r/min | 120r/min | 120r/min | 120r/min | 120r/min | |
| Blade Type | Dryland blade | Dryland blade | Dryland blade | Dryland blade | Dryland blade | |
| Dimension | 1350×360×1000 mm | 1400×820×1000 mm | 1500×850×1000 mm | 1250×850×1000mm | 1500 ×1050 × 1000mm | |
| Net weight | 34kg | 60kg | 62.5kg | 78 kg | 131kg/145kg | |
