Features:
Self-priming design (require initial priming to operate)
Suitable for general water transfer, irrigation, garden, mining and civil engineering
Forged strong cast iron pump body
Forged iron volute impeller
High quality ceramic plunger, silicon carbide water seal
Low oil consumption, low noise
Powered by advanced YARMAX engine, reliable performance, easy start
| Model | YMDP20S | YMDP30S |
| Fuel Tank | 5.5L | 3.5L |
| Start system | Manual & Electric | Manual & Electric |
| Type | Self priming, centrifugal pump | Fully Automatic waterless self-priming pump |
| Inlet | 2"(50mm) | 3"(80mm) |
| Outlet | 2"(50mm) | 3"(80mm) |
| Max.head | 88m | 83m |
| Max.Flow | 426L/min | 800L/min |
| Pump body | Cast Iron | Cast Iron |
| Impeller | Cast Iron | Cast Iron |
| Engine type | Forced air cooled,4-stroke Diesel engine | Forced air cooled,4-stroke Diesel engine |
| Engine Model | 192F | 192F |
| Displacement | 498cc | 498cc |
