Specifications:
base Parameters
Nominal Voltage (OCV): 48V
Rated Capacity (Ah): 10.4
Power (Wh): 499
Cell: SAMSUNG 18650- 2600mAh
BMS: Smart BMS
Voltage Scope (V): 36-49.2
Internal Resistance: < 240
Charge Mode: CC-CV (Special 5P Charger)
Continuous Charge Current (A): 2-4
Charging Time (H): 6.5 Hours with 2A Charger
Maximum Continuous Discharge Current (A): 18
Matching Parameter
Position: Carrier
Weight (kg): 3.5
Controller Box: Front / Rear Motor
Carrier: Optional
IP-Code: IP65
