Doing Company has a professional starch syrup equipment design and making team, can provide you good quality set of starch syrup equipments. If you want to know how to make glucose syrup from starch, following is the answer:
Following is glucose syrup manufacturing process details:
1. Starch quality check and transfer:
The starch water contain should be less than 14%, and starch not weird. Next transfer the starch to mixing tank.
2. Glucose syrup mixing and liquefaction section:
Mixing
the starch with clean water, make the concentration to 18Be, PH value
get to 5.6-6.0. put into the α-enzyme, then deliver the liquid to jet
cooker with steam heating temperature 100-108℃ to make liquefied process
of glucose syrup production process.
The starch liquid is delivery to plate frame filter press machine to remove the protein then the separated proteins can be washed, dried and crushed to packed into the warehouse changed to animal feed. This increase the add-value of your glucose syrup equipment.
4. Saccharification section:
This
section use the saccharifying tank, adjust the liquid temperature to
60℃, PH value 4.2-4.8, put saccharify enzyme, then keep 36-50 hours.
5. First decoloring section:
Adding
activated carbon to the liquid, this part time need 0.5 ~ 1 hour, then
send the liquid to plate frame filter press machine for decoloring then
can get bright and pure glucose syrup, this time the transmittance of
the solutions should more than 75% of our glucose production machinery.
6. First Ion exchange:
When
the solutions temperature is decreased about 42℃, then to ion exchange
column. The conductivity value of the final liquid is less than 20ppm.
7. Pre-concentration section:
After ion exchange process, pre-concentration the glucose syrup liquid to 45Bx.
8. Second decoloring:
Also use activated carbon to make decoloring by glucose production machinery, but this time the transmittance should be 95%.
9. Second ion exchange:
This
time should decrease the temperature to 30-35℃, then transfer to ion
exchange system, then conductivity of the glucose syrup is more than
95%.
10: Glucose syrup evaporation process:
In this section, evaporator usually used three-effect type.
In recent years, with the continuous develop of people's consumption level, food and beverage industry rapidly develop, the demand quantity of suguar also increased a lot. But on the other hand, because of the petroleum international price risen, Brazil and other sugarcane major origin area and countries increase the quantity of sugarcane cost in fuel processing, then the sugar with the rise in price. Nowadays, the industrial production of glucose mainly made by corn starch which can substitute sugar or as a good supplement has been get more and more concentration. The specilized said, compact with sugar, corn starch has a higher competitiveness, not only in health and practicality, but also in price, with a strong market develop prospect. Click syrup machine to learn more related.
