Micron |
1μm, 5μm(operation filter), 10μm(startup filter) |
|
|
Filter area |
6.5m² |
|
|
Maximum Operating Temperature |
85℃ |
|
|
Maximum Operating Differential Pressure |
2.8bar, 65℃ |
|
|
Design Flow Rate |
3.9m³/h～4.5m³h |
|
|
Parts Material |
Filter Media |
Polypropylene |
|
Center Core |
Reinforced Polypropylene |
|
|
Dimensions(nominal) |
Outside Diameter |
69mm, 65mm(PHFZ-Ⅲ (3 + 1)) |
|
Length |
70" |
|
|
Connection Thread |
1 1/2"-12(Customized as customers’ request) |
|
|
Bottom Thread |
M6, M8, M10 |
|
