Product Description
RDT-RT3 indoor LED screen new cabinet 768mm*768mm can be used both fixed and rental installation with front service, easily installation and very cheap price under higher quality compared to P3,P3.91 normal cabinet.
Advantages:1.Thicker PCB:1.6mm, 2.Higher refresh rate:3840HZ 3.Stable quality 4.HD display 5.Lower cost 6.Both using for fixed and rental 7.Both front and back service 8.Fast delivery time
Die-casting aluminum panel, to achieve high precision process to seamless and good thermal dissipation; to support the entire screen of any size to a truly seamless splicing.
Jointed correctly, being installed & dismounted by one person.
Slim and light weight.
Convenient in transporting and installing & saving labor cost, suitable for flow shows.
| RT3 Indoor LED | ||||
| Pixel Pitch | 3.0mm | |||
| LED Type/Brand | SMD (3-in-1) | |||
| Brightness(nits) | 0-1500(adjustable) | |||
| Cabinet Size(mm) | W:768mm x H:768mm | |||
| Module Size (mm) | 192mm * 192mm | |||
| Pixel/Cabinet | W:192 x H:192 | |||
| Pixel/M² | 111,111 | |||
| Viewing Angle(H/V) | 160/140 | |||
| Controller(Optional) | NovaStar | |||
| Weight/cabinet | 13kg(Complete panel) | |||
| Color Depth | 14-16 bit | |||
| Contrast | ≥3000:1 | |||
| IP rating | IP43 | |||
| Scan | 1/32s | |||
| Refresh Rate | ≥3840 Hz(Adjustable) | |||
| Max Power/sqm | 630 W | |||
| Avg. Power/sqm | 220 W | |||
| Working Temp | -20º~60º | |||
| Service method | Front&Back optional | |||
| Standard | CE, FCC, RoHS, CCC, ISO9001 | |||
