UH 4-20mA industrial CH4 natural gas sensor is a device for a single or multiple combustible gas concentration response. This gas sensor has catalysis, infrared optical two kinds of type. Catalytic type combustible gas detector is to use refractory metal platinum rose after heating resistance change to determine the combustible gas concentration.
Features:
* Non-interfering, intelligent detector boundary
* Output: 4~20mA
* Unique automatic fault diagnosis function
* Catalytic sensor
* Low energy consumption
* Detect natural gas, lpg, CH4, alcohol
Details:
* Technical Parameter:
* Environmental Parameters:
Environmental temperature: -40 degree Celsius ~ 70 degree Celsius
Relative humidity: less than 90%R.H
* Technical Parameter:
Operating Voltage: 16~30V DC
Operating Current: 120mA
Output signal: 4~20mA standard signal three-wire system output
* Sensor: Die cast aluminum catalysis incendiary sensors
* Respond: less than 30s
* Measuring range: 0~100%LEL
* Installation Parameter:
Installation type: Wall-mounted
Transitions cable: Three conductor cable shielded cabling, section: 3x1.5mm2, external diameter: 10mm
Transmission Distance: less than 1000m
* Explosive-proof grade: Exd IICT6
* Protection Grade: IP65
* Connector: G3/4
Widely used in hotels, factories, metallurgy, petroleum, petrochemical, chemical industry, light industry, coking, municipal, gas, pharmacy, sewage treatment and many special industries and fields.
