3D Wire Mesh Fence

3D Wire Mesh Fence


Description

Wire diameter: 2mm-6mm

Height: From 630 to 2430 mm(as your requirement)

Available

Stainless Steel Welded Wire Mesh/Galvanized Welded Wire Mesh/Hot-dipped Galvanized Welded Wire Mesh/ PVC coated Welded Wire Mesh/Painting Welded Wire Mesh/Welded Wire Mesh Panel/Welded Wire Mesh Fence

Application

The welded mesh fencing can be used for gardens, factory, road , highway, public buildings , parks, government buildings, ball court, industry & commercial sector.

Packing

>Fence panel:plastic film+wood/metal pallet

>Fence post:every post pack with a plastic bag(the cap is covered well on the post)+metal pallet

>Accessory:small plastic bag+carton box

Advantages

1. Cost Effective

The welded mesh panels provide competitive price levels whilst retaining high quality, rigidity and performance.

2. Long Life

Galvanized and PVC coated of corrosion resistance for long life and low maintenance and attractive appearance.

3. High Strength

The panels are welded from strong steel wire, with rectangular mesh and horizontal reinforcements that give the panels a high strength.

4. Rapid Installation

All components attractive fence with the other components which achieves professional and high quality fencing, installed with maximum effectiveness.

Specification

* Horizontal bars with a V-shaped bend of the panel give greater

* stiffness.

* Panel ends protruding 30 mm pins, which can be placed both at the bottom and the top.

* Width: 2500 mm.

* Height: from 630 to 2430 mm.

* Cell size: 200 x 50 mm.

*Cell Size curved portion 100 x 50 mm.

* Wire diameter: 5.00 mm.

Height (m)	Width (m)	Wire Dia. (mm)	Opening (mm)	Surface Treatment	Color
1.0m	2.0m 2.5m	4.0mm 4.5mm 5.0mm	50x200mm 55x200mm 50x150mm 50x100mm	Galvanized + powder coated; Galvanized + PVC coated; Hot dipped Galvanized	RAL6005 Green, RAL7016 Gray, RAL9005 Black, RAL8014 Brown, RAL9010 White, and other RAL colors
1.2m
1.5m
1.7m
1.8m
2.0m

Post Type	Post OD.	Wall Thickness (mm)	Surface treatment	Color
Square Post	40x60mm, 60x60mm	1.2mm, 1.5mm, 2.0mm	Galvanized + PVC coated; Hot dipped Galvanized	RAL6005 Green, RAL7016 Gray, RAL9005 Black, RAL8014 Brown, RAL9010 White, and other RAL colors
Peach Post	50x70mm, 70x100mm	1.0mm, 1.2mm
Round Post	OD48mm, OD60mm	1.2mm, 1.5mm, 2.0mm

Production process

Iron steel wire→Wire drawing→Rust removing → Straighten wire →Cutting wire→Welded Black fence panel→Bended → Acid washing →Galvanizing→Cleaning&Drying→PVC Spray or Coating→Inspecting Quality→Packing .

Packing & delivery

1. Wire Mesh Fence Packing:

> Fence panel:plastic film+wood/metal pallet

> Fence post:every post pack with a plastic bag(the cap is covered well on the post)+metal pallet

> Accessory:small plastic bag+carton box

2. Delivery:

In general about 10-20days.(according to the quantity)
