Above electrical layout takes a three stations combination machine as an example.
- Operation box.
- Electrical cabinet.
- Add END motor.
- END quantity sensor.
- Handwheel
- Junction box.
- Body reference sensor.
- END reference sensor.
- END de-stacking sensor.
- Body (CAN) feeding motor.
- Body (CAN) enough (far) sensor.
- Lack of Body (CAN) (Near) sensor.
- Can-stop.
- 1# station body-in sensor.
- 2# station body-in sensor.
- Lack of END sensor.
- END send-out sensor
- No END in magazine sensor.
- 3# station body-in sensor.
- 3# station body-out sensor.
- Main motor.
- Body (CAN) Output motor.
- Body (CAN) Output jam sensor.
- Vertical design easy to connect with other machine
- Recycled central lubricating system
- Use inverter for variable speed control
- Full automatic control system for can making line requirement
- Multi-safety design for machine and personnel safety
- Cost saving by using thinner metal
- Suitable can diameter : 52-189mm
- Suitable can height : 50-245mm
- Production speed : 60-500cans/min
