+ Adopt 30Kpps high speed scanner module.
+ Prestet any gobos,words and mixed gobos in memory.
+ Set 64-256 gobos to form thousands of effects.
+ Emit two or more gobos at the same time.Feature such as weltering,revolving,XY moving,color and speed adjustable inside each gobo.Clients can design the gobos and words as their needs.
+ Modulation:TTL.
+ With ILDA standard DB25 connector,international standard DMX 512 connector.connected to Phoenix(Germany) or Pangolin(USA)control software,operating easily.
+ Application:Disco,Clubs,KTV,
Pub,TV station,Vocal concert,Advertising prommotion,etc.
Technical Parameter:
Voltage:AC100-240V 50/60Hz.
Power Consumption:200W.
Operating Temperature:10-40celsius degree.
Laser color:RGB.
Laser power:R635nM-1W,G520nM-1W,B445nM-2W.
Beam angle:±30 degree.
Control mode:Music,Automatic,Maser-Salve,DMX512/ILDA/SD card.
DMX channel:25CH.
Size:41*34*28cm.
N.W:7.5kgs.
G.W:9.5kgs.
Product link:
http://www.phoenix-lighting.com.cn/Product_Show.asp?PhotoID=646
