LED High Mast Pole Light
| Suitable height: | 18M ~35M |
| Process: | Using high-quality steel material, hot-dip galvanizing inside and outside after overall welding |
| Jacking system: | Yes |
| Light pole style: | Pyramidal |
| Service time: | 10 years |
| Applicable places: | City square, station, dock, highway, stadium, overpass lights |
Product Details
1. LED light source
2. The standard parameters
| Pole height | Lower caliber | Upper caliber | Weight | Opening height | Chassis size | Foundation size | Adaptive light source |
| 35m | 712 | 350 | 5257kg | 600 | Φ1200*25mm | 4m*4m*3m | 12-20(500-1000W) |
| 30m | 630 | 280 | 3745kg | 600 | Φ1050*25mm | 3. 8m*3.8m*2.8m | 12-20(500-1000W) |
| 25m | 550 | 250 | 2230kg | 600 | Φ 900*20mm | 3.5m*3.5m*2.5m | 10-16(250-400W) |
| 20m | 490 | 240 | 1662kg | 600 | Φ 900*20mm | 3m*3m*2. 5m | 8-12(150-250W) |
| 18m | 480 | 240 | 1477kg | 600 | Φ 750*20mm | 2m*2m*2.5m | 8-12(150-200W) |
| 15m | 255 | 95 | 406kg | 500 | Φ 550*20mm | 1.5m*1.5m*2m | 6-8(100-200W) |
| 12m | 210 | 75 | 208kg | 500 | 400*400*18mm | 1m*1m*1.2m | 4-6(100-200W) |
3. High mast pole light manufacturing equipment
Hengye specializes in the purchase of large-scale automated production equipment for high mast lamps, street lamps and monitors, ensuring accurate size, cost reduction and quality assurance to meet different orders, quantity and manufacturing difficulty.
