1.4 to 5.3 GHz 4-way Power Divider- Panda Microwave
Click image to view original image
Brand: Panda Microwave
Price: Negotiable
Min.Order:
Supply
Delivery: Shipment within 3 days since the date of payment
Address: China
Valid until: Never Expire
Updated on: 2019-07-04 12:23
Hits: 56203
Enquiry
Company Detail


Details
Description Minimum Typical Maximum Units Condition
Freq. Range 1.4 5.3 GHz
Nominal Splitter Loss 6.0 dB
Insertion Loss 1.5 dB Excluding Nominal Splitter Loss 6.0dB
Input VSWR 1.5
Output VSWR 1.5
Amplitude Balance 1 dB #1
Phase Balance 10 deg #2
Isolation 20 dB
Forward Power 10 W CW
Reverse Power 1 W CW
Peak Power 1 KW P-P
Impedance 50 Ohms
Operating Temp. -40 +70 ℃


1.4 to 5.3 GHz 4-way Power Divider- Panda Microwave
