Main Specifications
Size: 350mm-1000mm
Capacity: 1200-16000 m3/h
Head: 10-40m
Material: metal liner, Rubber liner,
Seal: Mechanical seal
Pump Features
1. Series of TL(R) FGD pump is a single-stage ,single-suction ,horizontal centrifugal pump .
This series pump is matched by tight structure X bracket. It mainly used as the circulating pump for absorbent tower in FGD appliances. It has such features: wide rang flowing capacity ,with high efficiency, high saving power.
2. Bearing lubricating way: diluted oil
3. This kind of pump adopts back pull-out structure keeping it easy construction and easy maintenance.
It does not need disassemble inlet & outlet pipeline.
Material Selection
1.In the rubber pump casing, impeller, suction cover and cover plate are all made of specialized anti-wear and anti-corrosive material; the material of the front liner, back liner and back liner insert are natural rubber with light weight and natural, having excellent anti-corrosive property and low cost.
2. In the metal pump casing, impeller, volute liner, suction plate and back plate are all made of specialized anti-wear and anti-corrosive material; the suction cover are made of ductile iron with rubber.
Pump Code Explanation
Pump Structure
Type TLR Pump
1. Bracket 2. Impell disassembling ring 3.Shaft sleeve 4.Mechanical sealing 5.Back plate liner
6. Front plate liner 7. Suction cover 8. Impeller 9. Top casing 10. Back liner 11. pump casing
12.adaptor plate
Type TL Pump
1. Bracket 2. Impell disassembling ring 3.Shaft sleeve 4.Mechanical sealing 5.Back plate liner
6. Front plate liner 7. Suction cover 8. Impeller 9. Top casing 10. Back liner 11. pump casing
12.adaptor plate
Pump Parameter
