Skived Fin heat sinks can be an alternative to extruded heat sinks when looking for a fin density which can’t be achieved by extrusion technology. Skived heat sinks can be manufactured from either copper or aluminum and usually have 0.5 (0.020”) thick fins.
|
Place of Origin |
Dongguan China |
Material |
Aluminum/Copper |
|
Shape |
Square |
Material&Temper |
Alloy 6063-T5/6061-T6/CU1100 |
|
Model number |
SK-2 Skived fin |
Process |
Skived |
|
Item |
Heatsinks |
Fin thickness |
0.25 --2 mm |
|
Finish |
Anodized |
Certificate |
ISO9001,ISO14001 |
|
Extra process |
CNC maching |
size |
Customized |
|
Length |
Less than 2m |
OEM |
Yes |
|
Application field |
Telecommunication, UPS, inverters, controllers, wind power converters, and LED lighting |
||
Material: Copper ,Aluminum or Alloy
1 Skiving Technology .
2 Customized design.
3 High density copper heat sink. increasing the cooling area, better heat dissipation.
4 Factory price and high quality heat sink.
Skived fins are achieved by a knife tool that literally shaves fins up from an extruded aluminum or copper base. This process of slicing and then standing the fins up one at a time can create an extremely high fin-to-gap aspect ratio. The top of the fins are then cut to maintain a uniform height. This increased surface area drastically improves the thermal performance in forced airflow environments.
Skived fin heat sinks are commonly found in the following applications:
Computers and electronic components
Telecommunication equipment
Industrial equipment and components
Lighting lamps and household appliances industry
Automotive components
15 years experience in Custom heat sinks and Skiving production .Our focus has always been to provide superior customer service in the high quality cost-effective custom heat sink area. Any custom heatsinks and standard heatsinks demand, please contact Pioneer Thermal. We'll reply you within 12 hours.
