Bearing for motorcycle 6202 C3 P5 Single ball bearing
Click image to view original image
Price: Negotiable
Min.Order: 500
Supply
Delivery: Shipment within 30 days since the date of payment
Address: China
Valid until: Never Expire
Updated on: 2020-02-09 18:23
Hits: 33895
Enquiry
Company Detail


Details







Technical Parameter
Axial clearance  C3 Max Speed 20,000 rpm
Bore diameter 15mm Operating temperature  -40℃-150℃
Outer diameter 35mm Dynamic load rating 7.64KN
Outer ring width 11mm Static load rating 3.72KN
Inner ring width 11mm Inner ring material GCr15
Minimum assembly chamfer 0.6mm Outer ring material GCr15
Net weight 0.046kg Steel ball material GCr15
Packing industrial package Retainer material SPCC
Packing number 500pcs Seal ring material 　
