Small scale palm kernel oil extraction machine palm kernel pressing machine

Product Description



Palm kernel accounts for 6.5% of palm fruit bunches, and the oil content rate of palm kernel is about 50-55%, also, the palm kernel oil can be used to process various products such as chocolate and margarine etc. So there is a hugh market behind palm kernel oil processing, our company has professional engineers who are good at the designing and developing of palm kernel oil press machines, our palm kernel oil press machine includes cleaning, cooking, pressing and oil filtration. After this, you will get crude palm kernel oil which can be sold or deeply processed.

We can supply 1-600TPD (tons per day) capacity of palm kernel oil pressing line





Work flow of palm kernel oil processing machine:

Palm kernel(with shell)--Husking--Cooking--Pressing--Filtration--Crude palm kenel oil&cake





1.Palm kernel with shell cracking and separation step:

if the raw material palm kernel is with shell, first you need to remove the shell. We have specific palm kernel cracking&separating system which can separate the kernel and shell very cleanly. After crushing the palm nut, the shell and kernel weight is very close; to separate it is a very complicated process; we adopt professional palm kernel cracker, Then use air separator system, through adjusting the transducer to control high pressure air speed and volume.





2..Cooking step:

the main function of this part of pam kernel oil press machine is wetting , heating, cooking and drying the the flakiness, the effectiveness of the cooking will affect the oil out rate and the quality of the meal.





3.Pressing step:

since palm kernel is hard and strong, it needs speicial palm kernel oil press machine which has powerful drive and pressing bolt.Our palm kernel oil press machine are especially designed for pressing palm kernel oil.



4.Filtration step:

after pressing by the palm kernel oil press machine,there will be some solid impurities in the crude oil, we can use the plate filter to remove most part of the impurities. If  you want to get higher degrade palm kernel oil, you can choose to refine it.



Specification of small scale palm kernel oil processing machine:

Number	Item	Power	Remark
1	Cooker	3.0kw	Heat by biomass or electricity, automatic in and out
2	Palm kernel oil presser	30kw	Professional CPKO press machine, low oil residue and high efficiency
3	Oil filter	1kw	Filter the crude oil.
