The animal feed processing equipment is widely used in animal feed pellet plant who produce feed pellets for chicken, rabbit, cow, sheep, cattle, pig, and so on. The reason why they make feed pellets by animal feed milling machine is that pellets are a balanced combination of different kinds of nutrition for the better growth of livestock, poultry and other animals.
| Model No. | Main motor power | Capacity(t/h) | Ring die inner diameter (mm) | Feeder power (kw) | Conditioner motor power (kw) | Size (mm) | Weight (kg) |
| KMPM25 | 22kw | 1-2 | 250 | 0.75 | 1.1 | 1750×650×1750 | 800 |
| KMPM32 | 22kw×2 | 2-5 | 320 | 0.75 | 2.2 | 1900×1800×1650 | 2000 |
| KMPM35 | 30kw×2 | 3-7 | 350 | 0.75 | 2.2 | 2100×2000×1850 | 2400 |
| KMPM40 | 45kw×2 | 4-10 | 400 | 1.5 | 4 | 2200×2000×2150 | 2900 |
| KMPM45 | 55kw×2 | 6-15 | 450 | 1.5 | 4 | 2300×2350×2150 | 3500 |
Ring die type large animal feed production machine have 2 types, one is single conditioner type, the other is double conditioner type. You can choose according to your needs.
Features of ring die feed pellet making machine
This model uses double motor SPB strong narrow belt transmission system, has ideal transmission efficiency, rotation steady, output high, noise low, no oil leak pollution, maintenance cost low;
This model has φ1.5-φ12mm many kinds of aperture and thickness link model; the user can wilfully select according to different need to obtain the best technology and economic efficiency;
Fixed stainless steel pelletizing knife equipment, adjustment is more intuitionistic; Quick-discharge anchor ear link model, can match coordinated type pressure roller regulating mechanism and link mold hoisting equipment;
This model uses transducer control material feeding, has over loading protector, outboard discharging mechanism.
Push-brace oil pump lubricating gear, quick and saving labour, safe and reliable, can realize to refuel without stopping engine;
It is suitable to high quality animal and poultry feed, aquatic product feed and other materials pellet.
