Concrete Pump parts Twin Wall delivery pipe
Basic Info
|
Model No.: DN125 |
Material: High Chromium Alloy |
|
Size: DN1100/DN125/DN150 |
Type: Double Layer Pipe |
|
Length: 3m/6m/9m/12m |
Color: Red/green/yellow/white And So On |
|
Outer Diameter: 133mm |
Service Life: 50000cbm-80000cbm |
|
Thickness: 4.5mm/5.0mm/5.5mm/7.0mm |
Application: Stationary Pump |
|
Flange Type: Sk148mm |
|
Additional Info
|
Packaging: bundling or plastic or according to clients requirement |
Place of Origin: cangzhou city |
|
Productivity: 500 thousand pieces per month |
Supply Ability: Timely and efficient,50000 pieces each time |
|
Brand: SDBL |
Certificate: ISO9000 |
|
Transportation: Ocean,Land |
HS Code: 87089960 |
|
Port: Tianjin Port,Shanghai Port |
|
SDBL Concrete Pump Twin Wall pipe Description
concrete pump twin wall delivery pipe
Hebei shengdebaolong can produce the best quality concrete pump twin wall delivery pipe, this kind of double layer pipe service life is longest , usually have boom pipe and deck pipe,have different thicknesses and lengthes.
a. Product name: Concrete Pump Spare Parts - double layer pipe and tube
b. Type: Concrete Pump Boom Pipe and deck pipe
c. Thickness (outer pipe thickness+inner pipe thickness): 2+3mm, 2+3.5mm, 3+4mm and so on.
d. Material: (1) Inner pipe is high chromium alloy steel ,outer pipe is alloy casted steel, this kind of twin wall pipe quality is equal to Conforms and Geramny Esser pipe, delivery capacity can reach 10000cbm, of course the price is highest.
(2) Inner pipe is 65Mn, outer pipe is 20# steel , this kind of tube is our usual exported pipe , service life is 50000cbm-80000cbm, price is lower, this kind of pipe cost performance is good, exported to many countries!
e. Service life: 50000cbm-100000cbm
f. Technoloy: this double layer tube inner wall pipe through heat treatment, also put one layer 20#pipe to protect the inner wall pipe, and then automatic welding the flange collar, Sand blasting, finally is Electrostatic spraying.
