1. Main body: The poultry feed making machine body is an independent rectangular cylinder. The upper part is connected with the powder hopper with a closed bearing seat. The powder hopper extends out of the poultry feed making process machine body. A V-shaped chassis is installed under the body. The floor is wide and flat, so the lower part must be installed. , Can be placed indoors arbitrarily
2. Pellet manufacturing device: The rotating drum is placed horizontally under the powder hopper, and there are bearing supports at the front and back. It is driven by the rack to rotate backwards and forwards. The front bearing cover on the end surface is movable. The next wing nut, the bearing cover and the rotating drum can be drawn out. The two ends of the placed drum are made with convex square rings, which are embedded in the bearing chamber, so that the oil will not penetrate into the powder and will not be blocked by adhesion.
3. Reduction gearbox: worm gear transmission, 1:12 speed ratio, oil can be stored in the box to ensure good gear lubrication and no noise, there is a sight glass on the box to observe, observe the operation and oil storage, the outer end of the worm gear, Equipped with an eccentric shaft to drive the rack to reciprocate.
4. Screen clamp pipe: The device is installed on both sides of the rotating drum and is made of steel pipe. There is a long groove in the middle. The two ends of the screen are embedded in the groove, and the flower-shaped handwheel is turned to wrap the screen on the outer circle of the rotating drum. The hand wheel is supported by gears, and the tightness can be adjusted.
5. Motor frame: One bolt is fastened to the screw, and the motor is installed on the iron plate. When the screw bolt is rotated, the motor moves up and down to adjust the belt.
