Glan Taylor Polarizer
Glan Taylor prism polarizer is made of two same birefringent material prisms that are assembled with an air space. It has a length to aperture ratio less than 1.0 makes it a relatively thin polarizer. The polarizer with no side escape windows are suitable for low to medium power online_ordering where the side rejected beams are not required, which is suitable for a wide variety of online_orderings, particularly with collimated input beams. The angular field of different materials of polarizers listed below for comparison.
Angular Field vs Wavelength
Specifications:
|
Material:
|
a -BBO, Calcite or YVO4
|
|
Wavelength Range:
|
a -BBO: 200-3500 nm, Calcite: 350-2300 nm, YVO4: 400-5000 nm
|
|
Extinction Ratio:
|
Calcite:<5x10 -5 ; a -BBO:<5x10 -6 ; YVO4:<5x10 -6
|
|
Parallelism:
|
<1 arc Min
|
|
Surface Quality:
|
20-10
|
|
Beam Deviation:
|
< 3 arc minutes
|
|
Wavefront Distortion:
|
l/4@633nm
|
|
Damage Threshold:
|
>200 MW/cm 2
|
|
Coating:
|
Single Layer MgF2
|
|
Mount:
|
Black Anodized Aluminum
|
Standard Products
1. Calcite Glan Taylor Polarizer
|
Part No.
|
Wavelength Rang(nm)
|
Extinction Ratio
|
Angular Field(°)
|
C.A. fa(mm)
|
O.D. fd(mm)
|
L ±0.1(mm)
|
|
GTP6006
|
350-2300
|
<5x10-5
|
>7.7
|
6.0
|
15.0
|
15.0
|
|
GTP6008
|
8.0
|
25.4
|
17.0
|
|||
|
GTP6010
|
10.0
|
25.4
|
19.0
|
|||
|
GTP6015
|
15.0
|
30.0
|
23.0
|
|||
|
|
|
|
|
2. a-BBO Glan Taylor Polarizer
200-270nm， 300-700nm, 700-3000nm
Note：Custom designs for other sizes and coatings are also available upon reques3. YVO4 Glan Taylor Polarizer
