Wollaston Polarizers
|
|
|
Wollaston polarizer is made of two birefringent material prisms that are cemented together. The deviations of the ordinary and extraordinary beams are nearly symmetrical about the input beam axis, so that the Wollaston polarizing beam splitter has approximately twice the deviation of the Rochon. The separation angle exhibits chromatic dispersion, as shown in the blow. Any separation angle can be designed upon the requirement. The separation angle of standard products vs wavelength is shown in the plot below.
Separation Angular of Standard Products vs Wavelength
|
Material:
|
a-BBO , Calcite , YVO4 , Quartz
|
|
Wavelength Range:
|
a-BBO:190-3500 nm, Calcite:350-2300 nm, YVO4:400-5000 nm, Quartz:200-2300 nm
|
|
Extinction Ratio:
|
Calcite,Quartz:<5x10-5; a-BBO , YVO4:<5x10-6
|
|
Parallelism:
|
<1 arc Min
|
|
Surface Quality:
|
20/10
|
|
Beam Deviation:
|
< 3 arc minutes
|
|
Wavefornt Distortion:
|
λ/4@632.8nm
|
|
Damage Threshold:
|
>500 MW/cm2
|
|
Coating:
|
Single MgF2
|
|
Mount:
|
Black Anodized Aluminium
|
Standard Products
1. a-BBO Wollaston Polarizer
2. Calcite Wollaston Polarizer
3. Quartz Wollaston Polarizer
4. YVO4 Wollaston Polarizer
Note：Custom designs for other sizes and coatings are also available upon request
