Heat Soaked treatment Glass allows the tempered glass that may spontaneous after installation to be artificially broken in the furnace in advance, thereby reducing the self-explosion of the tempered glass in use after installation. The spontaneous rate of conventional size glass can be reduced to less than 0.1% after HST treatment. This processing provide a safer guarantee for some tall buildings.
|
Glass Type |
Heat Soaked Glass |
|
Glass Thickness |
3mm, 4mm, 5mm, 8mm, 10mm, 12mm, 15mm, 19mm, 22mm, 25mm thick heat soaked glass. |
|
Tolerance |
As per SGCC CE standards |
|
Glass Color |
Clear Heat Soaked Glass, Low Iron Heat Soaked Glass, Super White Heat Soaked Glass, Super Low Iron Heat Soaked Glass, Super Clear Heat Soaked Glass, Extra White Heat Soaked Glass, Starphire Heat Soaked Glass, Optiwhite Heat Soaked Glass, Euro Grey Heat Soaked Glass, Dark Grey Heat Soaked Glass, Crystal Grey Heat Soaked Glass, Brown Heat Soaked Glass, Bronze Heat Soaked Glass, Ocean Heat Soaked Glass, Ford Blue Heat Soaked Glass, Dark Blue Heat Soaked Glass, etc. |
|
Size |
Custom Size |
|
Max size |
18000mm L*3660mm H |
|
Edge Work |
Flat Edge, Seamed Edge, Polished Edge, Bevelled edge, Flat Polished Edge, Round Edge,Arrised edge, C Shape, etc. upon your request. |
|
Irregular Shape |
Rectangular, Round, Oval, Trapezoid, Parallel, etc. All edges can be bright polished. |
|
Hole & Notch |
Countersunk holes, round holes, bell-mouth holes, simple notch, mickey ears cutouts, etc. The edge of hole and notch can be polished by CNC |
|
Trade Terms |
FOB, CIF, DAP, DDU,etc |
|
Lead Time |
Generally 2-4 weeks |
|
Terms of Payment |
30% down payment before production, 70% balance TT at shipment, L/C. |
|
MOQ |
To be discussed |
|
Added-on options: acid etched, color painted, digital printing, silkscreen printing |
|
Advantages:
3 to 6 times stronger and unbreakable than normal annealed glass
Should glass is break, far less risk of injury from broken pieces
Energy-saving by adding on low e coating and reflective coatings
Sound control
Can withstand 200℃ temperature change
Eco-friendly
●Visually-Enticing
Thermal Insulating
Reduce energy cost
Reduce destructive UV rays.
Northglass provide 19mm tempered heat strengthened glass.
Quality Standard:
In accordance with EN12543, European safety glass standard
In accordance with ANSIZ97.1, American and Canadian safety glass standard
In accordance with AS/NZS2208, Australian safety glass standard
Application:
Balustrade glass
Skylight glass
Canopy glass
Shower Screen Doors
Glass shelves
Doors And Window glass
Partition glass
Public Venues
