Brick Reinforcement Mesh Yingkang

Brick Reinforcement Mesh Yingkang

Embedded in the normal thickness of a brickwork joint, expanded metal reinforcement reduces the detrimental effects of vibration and changes of temperature. The application gives brickwork increased resistance to tensional stresses. The brickwork reinforcement (coil mesh) assists resistance to tensile stresses where settlement occurs. Easily incorporated into mortar course, coiled for ease of handing.

Applications:

concrete slabbing, roads, paving, foundations, marine work, bank strong rooms, partition slabs, concrete block work, asphalt guttering etc.Installation:
Fix into mortar between brick courses leaving 25mm clearance from face of brickwork. All joints require an overlap of at least 75mm. The mesh can be laid every third brickwork course for most reinforcement.

https://www.wirenetting-china.com/expanded-mesh/brick-reinforcement-mesh.html
Material:
Galvanized steel, stainless steel
Width: 65mm, 100mm, 175mm, 225mm, 300mm
Length: 20m

Size:
