| SPECIFICATION | 1000i | 2000i | 3500iO | 4000iO |
| Engine model | 152F-3 | 148F | 170F | 170F-2T |
| Engine type | 4-Stroke single-cylinder with air-cooled | 4-Stroke single-cylinder with air-cooled | 4-Stroke single-cylinder with air-cooled | 4-Stroke single-cylinder with air-cooled |
| Starting system | Manual | Manual | Manual/Electric | Manual/Electric |
| Bore*Stroke(mm) | 52*37.4 | 48.6*43 | 70*55 | 70*58 |
| Displacement(ml) | 79.5 | 79.7 | 212 | 223 |
| Max. power(50Hz/60Hz)kw | 1 | 1.8 | 3.5 | 4 |
| Rated power(50Hz/60Hz)kw | 0.85 | 1.6 | 3 | 3.5 |
| Rated voltage(V) | 120/220 | 220 | 120/220 | 220 |
| DC output(V/A) | 12/8.3 | 12/8.3 | 12/8.3 | 12/8.3 |
| Fuel consumption(g/kw.h) | ≤500 | ≤450 | ≤500 | ≤430 |
| Continous running time(h) | 5 | 3.8 | 8 | 8 |
| Fuel tank capacity(L) | 3.5 | 4.9 | 10 | 10 |
| Net weight(kg) | 15 | 22 | 37 | 42 |
| Noise(7m)dB | ≤54 | ≤66 | ≤68 | ≤70 |
| Carton dimensions(LxWxH)mm | 485*285*455 | 518*310*500 | 520*440*455 | 520*440*455 |
| Qty (20GP/40GP/40HQ) | 480/975/975 | 480/975/975 | 192/416/624 | 192/416/624 |
