| SPECIFICATION | 1200-B | 1200-3B | 1500 | 1800 |
| Engine model | 154F | 152F-3 | 156F | 160F |
| Engine type | 4-Stroke single-cylinder with air-cooled | 4-Stroke single-cylinder with air-cooled | 4-Stroke single-cylinder with air-cooled | 4-Stroke single-cylinder with air-cooled |
| Starting system | Manual | Manual | Manual/Electric | Manual |
| Bore*Stroke(mm) | 54*46 | 52*37.4 | 56*40 | 60*42 |
| Displacement(ml) | 105 | 79.5 | 98.5 | 119 |
| Max. power(50Hz/60Hz)kw | 0.8/0.85 | 0.85/0.9 | 1.1/1.2 | 1.3/1.5 |
| Rated power(50Hz/60Hz)kw | 0.75/0.8 | 0.8/0.85 | 1/1.1 | 1.2/1.4 |
| Rated voltage(V) | 110/120/220/240 | 110/120/220/240 | 110/120/220/240 | 110/120/220/240 |
| DC output(V/A) | 12/8.3 | 12/8.3 | 12/8.3 | 12/8.3 |
| Fuel consumption(g/kw.h) | ≤590 | ≤550 | ≤590 | ≤590 |
| Continous running time(h) | 5.7 | 5.7 | 4.9/5.5 | 7.6 |
| Fuel tank capacity(L) | 3.5 | 3.5 | 4/4.5 | 7.5 |
| Net weight(kg) | 24 | 23 | 28/29 | 30 |
| Noise(7m)dB | ≤63 | ≤63 | ≤63 | ≤63 |
| Carton dimensions(LxWxH)mm | 455*365*450 | 455*365*440 | 480*400*410 | 530*385*460 |
| Qty (20GP/40GP/40HQ) | 390/787/967 | 390/787/967 | 390/780/830 | 320/660/660 |
