| Model | LC12000 | LC12000-1 | LC13000 | LC22000 |
| Engine model | LC2V78FD-1 | LC2V78FD-1 | LC196FD | LC2V90FD |
| Engine type | Air-cooled,4-stroke,ohv90L,V-twin cylinders | Air-cooled,4-stroke,ohv90L,V-twin cylinders | Air-cooled,4-stroke,ohv90L,V-twin cylinders | Air-cooled,4-stroke,ohv90L,V-twin cylinders |
| Power output | 13.4kW/3600rpm | 13.4kW/3600rpm | 13.3kW/3600rpm | 22kW/3600rpm |
| Bore×Stroke | 78mm×71mm | 78mm×71mm | 96mm×86mm | 90mm×78.5mm |
| Displacement | 678cc | 678cc | 622cc | 999cc |
| Oil capacity | 1.6L | 1.6L | 1.6L | 2.5L |
| Ignition system | Transistorized magneto | Transistorized magneto | Transistorized magneto | Transistorized magneto |
| Starting system | Electric start | Electric start | Recoil start/Electic-start | Electric start |
| DC Voltage/current | 12V/8.3A | 12V/8.3A | 12V/8.3A | / |
| Rated frequency | 50 Hz/ 60 Hz | 50 Hz/ 60 Hz | 50 Hz/ 60 Hz | 50 Hz/ 60 Hz |
| Rated voltage | 220 V/230 V/240 V | 380 V/400 V/415 V | 220 V/120 V/240 V | 220 V/120 V/240 V/380/400/415 |
| Rated output | 8.5kW/9.5kW | 9kW/10kW | 8.5kW/9.5kW | 15kW |
| Max power | 9.5kW/10.5kW | 10kW/11kW | 9.5kW/10.5kW | / |
| Fuel tank capcity | 25L | 25L | 48L | 40L |
| Continuing time | 7h | 7h | 10h | 6h |
| Dimension | 868×635×676 | 868×635×676 | 800×620×650mm | 1034×720×715mm |
| Net weight | 160kg | 160kg | 143kg | 200kg |
