PCB Assembly

China PCBA Contract Manufacturing Factory Multilayer PCB Assembly



As a 20 years PCB manufacturer in China, FASTPCBA is providing the latest printed circuit board technologies and highest quality standards for electronics industry. You can trust us to meet your demands, from small volume to mass production whatever the simplest PCB boards or the most complex.





20 Years Experience
Accept Stardard: IPC III, Military, Automotive, Medcial, We offer you expanded PCB capabilities: Rigid PCB, Flexible, Rigid-flex, HDI board, High TG PCB



Up to 48 layer prototype PCB
Manufacture PCB board up to 56 layer, Raw material: Fr4, Rogers, Arlon, Teflon, Taconic, Nelco, Isola, Ceramic, metal core



Up to 18 layer mass production
Support PCB surface process: HASL-LF, ENIG, Plating gold, Immersion tin, Immersion silver, ENIPIG, OSP





Flexible Volume Assembly Alternatives:



For full turn-key, we take care of the entire process, including manufacturing of Printed Circuit Boards, procurement of components (100% original) , PCBA Testing , continuous monitoring of quality and final assembly.



1. Prototype PCB Assembly
2. Low-Volume, High Mix PCB Assembly
3. High-Volume PCB Assembly
4. Consigned & Partial PCB Assembly
5. Full Turnkey PCB Assembly
6. Cable & Wire Harness Assembly
7. Box Build Assembly Services





Process Capability:



Article	Description	Capability
Sercive	PCB and SMT assembly with one-stop service
Material	Laminate materials	FR4, high TG FR4, high frequency, alum, FPC
Board cutting	Number of layers	1-48
	Min.thickness for inner layers (Cu thickness are excluded)	0.003”(0.07mm)
Board thickness	Standard	(0.1-4mm±10%)
	Min.	Single/Double:0.008±0.004”
		4layer:0.01±0.008”
		8layer:0.01±0.008”
	Bow and twist	no more than 7/1000
Copper weight	Outer Cu weight	0.5-4 0z
	Inner Cu weight	0.5-3 0z
Drilling	Min size	0.0078”(0.2mm)
	Drill deviation	±0.002″(0.05mm)
	PTH hole tolerance	±0.002″(0.005mm)
	NPTH hole tolerance	±0.002″(0.005mm)
Solder mask	Color	Green,white,black,red,blue…
	Min solder mask clearanace	0.003″(0.07mm)
	Thickness	(0.012*0.017mm)
Silkscreen	Color	white,black,yellow,blue…
	Min size	0.006″(0.15mm)
E-test	Function Test	100% Functional test
	PCBA Testing	X-ray,AOI Test,Functional test
Pcb assembly	one-stop service electronic manufacxturer service
Component sourcing	Yes
Certificate	IATF16949, ISO13485, ISO9001, ISO14001
Delivery time:	PCB		3-8days
	PCBA		10-20days
Tolerance of pcb	±5%
Max size of finish board	700*460mm
MOQ	NO MOQ (1pcs)
Surface Finish	HASL,ENIG,immersion silver,immersion tin,OSP…
PCB outline	Square,circle,irregular(with jigs)
package	QFN,BGA,SSOP,PLCC,LGA
Sub-assembly	Plastic,metal,screen
