Product Description
Advantages:
►All the important parts like IGBT, diode, integrated circuit, relay, current and voltage regulator are world famous brand which have high reliability;
► Cutting gas source: compressed air, low cost
► IGBT: LGK-40/63IGBT: Single-tube IGBT
LGK-100/160/200/300IGBT: IGBT module
► Cutting process: Manual cutting, automatic cutting
► Soft switch technology, improve the IGBT and it`s reliability;
► 100%(40℃)duty cycle, it is suitable for long time, heavy load, high temperature and bad circumstances;
► Inverter control power source: small volume, little weight and energy saving;
► Current upslope function: reduce the impact on striking arc and decrease consumption of cutting torch parts;
► Air pressure, hydraulic pressure sensor: protect torch from being burnt efficiently;
► Machine type setting: Arc striking signal, arc pressure signal, air supply control and arc pressure output function makes it specially suitable for CNC and robot cutting;
► Two machines parallel use is available, double the output current to cutting extra-thickness material well.
Main Parameters:
