1. Overview
● STR5001X is designed as HGU (Home Gateway Unit) in deferent FTTH solutions, The
carrier-class FTTH application provides data service access.
● STR5001X is based on mature and stable, cost-effective XPON technology. It can switch
automatically with EPON and GPON mode when it access to the EPON OLT or GPON OLT.
● STR5001X adopts high reliability, easy management, configuration flexibility and good
quality of service (QoS) guarantees to meet the technical performance of the module of China
Telecom EPON CTC3.0 and GPON Standard of ITU-TG.984.X
2. Functional Feature
● Support EPON/GPON mode and switch mode automatically
● Support ONU auto-discovery/link detection/remote upgrade of software
● Support Route PPPoE/IPoE/Static IP and Bridge mode
● Support IPv4/IPv6 Dual mode
● Support Firewall function and IGMP multicast feature
● Support LAN IP and DHCP Server configuration
● Support Port Forwarding and Loop-Detect
● Support TR069 Remote Configuration and maintenance
● Specialized design for system breakdown prevention to maintain stable system
Hardware Specification
|
Technical item
|
Details
|
|
PON Interface
|
1 GPON BOB （Class B+/Class C+）
|
|
Receiving sensitivity: ≤-27dBm/≤-29dBm
|
|
|
Transmitting optical power:+0.5~+5dBm/+2~+7dBm
|
|
|
Transmission distance: 20KM
|
|
|
Wavelength
|
TX: 1310nm, RX: 1490nm
|
|
Optical Interface
|
SC/UPC Connector
|
|
Chip Spec
|
RTL9601D ,CPU 300MHz,DDR2 32MB
|
|
Flash
|
SPI Nor Flash 16MB
|
|
LAN Interface
|
1x 10/100/1000Mbps auto adaptive Ethernet interface. RJ45 connector
|
|
LED
|
4 LED, For Status of PWR、LOS、PON、link/ACT
|
|
Push-Button
|
2,For Function of Power on/off,Reset
|
|
Operating Condition
|
Temperature: 0℃~+50℃
|
|
Humidity: 10%～90%（non-condensing）
|
|
|
Storing Condition
|
Temperature: -30℃~+60℃
|
|
Humidity: 10%~90%（non-condensing）
|
|
|
Power Supply
|
DC 12V/0.5A
|
|
Power Consumption
|
<3W
|
|
Dimension
|
120mmx78mmx30mm(L×W×H)
|
|
Net Weight
|
NET Weight 0.13KG, Gross Weight 0.35KG
|
