1. High abrasion resistance
UHMWPE has the best wear resistance among all engineering plastics. The higher the molecular weight of the material, the better the wear resistance of the pipe is guaranteed. The abrasion resistance of UHMWPE pipe is 4-6 times higher than Q235 carbon steel pipe, 2.7 times higher than silicomanganese 13 wear-resistant steel pipe, and 3 times higher than HDPE pipe, which makes UHMWPE pipe very ideal for mortar and slurry discharge.
2. High impact resistance and ring stiffness
The impact resistance of UHMWPE pipe is 2 times that of PC and 10 times that of PTFE. It has good impact resistance and can withstand the impact from various sands, slurries and muds.
3. Low flow resistance coefficient, high transmission efficiency, saving pumping cost.
UHMWPE pipe has very smooth surface, low friction loss and high flow rate.
The Manning roughness coefficient of UHMWPE pipe is 00065, while that of steel pipe is 0012, which greatly improves the transportation efficiency and saves the pumping cost.
4. Minimize time and cost saving
UHMWPE pipe has good wear resistance and its rotation frequency is low, so the pipe replacement cycle will be greatly extended, which effectively reduces the total cost of the project. Due to good anti-adhesive property, UHMWPE pipes are not easy to scale, so there is no need for acid cleaning.
UHMWPE pipes have good corrosion resistance and do not need anti-corrosion treatment.
5. Light weight and easy to install
UHMWPES pipe is light in weight, its material density is 0945gcm3, about one-half of the weight of aluminum and one-eighth of the weight of steel, which effectively reduces the transportation, handling and installation into UHMWPE pipe can be connected by steel flange, easy to install and disassemble UHMWPE short end as a hot piece in the workplace, flat cover and good verticality will keep a good seal and can well protect the flange part from serious wear.
Applications:
UHMWPE pipeline is widely used in hydraulic reclamation, dredging, mine tailings, coal ash Han delivery and other fields.
