WMV680D Equine Anesthesia Machine-Large Animal

WMV680D Equine Anesthesia Machine-Large Animal     WonDCON Veterinary Anesthesia Machine

WMV680D Equine Anesthesia Machine is designed for use with Equine. Bovine. Zoology. and other large animal anesthesia techniques

PRODUCT DETAILS

Feature:

Respiration mode:Manual.open.closed.semi-open and semi-closed mode

Gas source:O2.0.3--0.4Mpa

O2 Flush:25L/min- -75L/min

Flow meter:high precision O2 flow meter. 0--1L/min--10L/min. O2&N2O or O2&N2O two tubes flow meter is option.

CO2 circle absorber: With soda lime chamber. APL valve. airway pressure gauge. inspiration valve and expiration

valve. the inspiration and expiration valve is demo-type and visible.

Airway pressure gauge: -20cmH2O--100cmH2O &-2Kpa--10Kpa

APL valve:adjustable easily. range:0-60cmH20

Soda lime chamber: 8Liter. it is easy to change soda lime and used for over 1000kg animal

Three methods: Table top and trolley and wall mounting arm. trolley is optional and wall mounting arm is optional

Bains connector: It is used for open breath circuit. connect with Jackson breath circuit or bains breath circuit.

Back bar: Supply selectatec compatiable mounting bar.ISO 23mm is compatiable

Anesthesia vaporizer: TEC3 vaporizer. Enflurane. Isoflurane. Halothane. Sevoflurane. one vaporizer with selectatec compatiable mounting bar. Cage mounting vaporizer is compatiable.

Trolley: There is a trolley to transport it.The trolley is optional.

Tidal Volume: 5000-15000ml

Standard configuration

Anesthesia machine with vaporizer,Disposable breath circuit, Reserve bag

O2 gas source pipeline,Stand

Optional configuration

Animal mask ,Bird mask ,Laryngoscope Endotracheal intubation

Rescue and Resuscitation,Bains breathing circuit,T-piece anesthesia breathing circuit

Reusable breathing bag,Disposable absorber of anesthesia exhaust gas

Anesthesia ventilator, ETCO2 monitor ,SPO2 monitor Patient monitor,Oxygen concentrator

Oxygen concentrator-anesthesia machine Stand, Anesthesia machine-ventilator stand

Induction Chambers
