华涛集团-瓦楞皮带机及备件
网址：www.htwirebelt.com www(dot)htwirebelt.com
邮箱：maple@huataogroup.com maple (at) huataogroup.com
电话：0086 133 8311 0583
微信：0086 133 8311 0583
机床适用机宽：1400 - 2200mm
规格：
1.最高机器速度：200m / min，切割长度为0.5m时速度为100m / min
2. 切割长度：500mm - 999mm，切割精度9±1mm
3.最多可预设999个电脑工作量，不自动改变工作量，与连接，轻松管理
4.All drive gear made of high quality alloy steel, which are heat treated and exactitude processed, high drive accuracy and long life
5.Circulating lubrication to insure lubricate and also help to clean and cool
6.Paper entering and out are separated, each have their frequency convert motor to control speed, synchronized driven, stable and low noise
7.Double-row round wheels are used at entrance to reduce the cutting errors caused by dithering of paper board.
8.Exit and sending platform use round wheels and conveyer belt, which make paper board ejection steady.
9.Round wheels device pneumatic controlled, special design, easy to operate
10.Pedestal and wheel box made of grey cast iron, good steel and good shake-resistance
11.AC伺服-控制系统节能30%以上
12.电机
主电机：37kw / 55kw
油泵电机：0.2kw
输送电机：2.2kw
