PP PPH Pipe Fitting PN10

PPH PIPE elbow 90 degree have two types, one is short radius with socket fusion connection, another is long radius with butt welding. the socket fusion type size from 20mm to 110mm, an butt wedling type size upto 315mm. different type used for different working condition. both PPH PIPE fitting PN10 elbow and PPH FITTING bend are designed as per standard DIN 8077/8078 with pressure rate PN10 bar.

RMI PLAST offer PPH pipe fitting PN10 with following specifications:

Size: D20mm to D400mm

Standard: DIN8077/8078
Working pressure: 1.0Mpa(PN10 bar)
Working temperature: 0ºC to 95ºC
