PVC Float Flowmeter model RPV164 is made by transparent AS body with PVC union connector and ABS coated steel floator, the function is to measure the flow rate of pipe system. FLOW METER is easy to observe the flow inside the system, PVC flow meter measuring range from 5l/h to 200m3/h, connect size from 20mm to 160mm by socket, and DN15 to DN150 by flange. Rota meter is used for water system and water treatment systems.
Basic specification
Size: DN15~DN150 (1/2 inch ~ 6 inch)
Connection: Flange, Socket
Body Material: AS, ABS, PVC
Floater material: ABS C/W steel
Measuring range: 5-50 l/h ~ 25-200 m3/h
Accuracy: 4%
Design pressure: 1.0Mpa (PN10 bar)
Feature of flow meter
All the parts that touch medium are made by plastic and stainless steel.
Measureing range is widely.
Union design is convenient to install and replace.
Transparent body is convenient to observe the medium, and diagnosis problem.
Suitable for vertical installation only
