Find the perfect Flanged High-Performance China Butterfly Valves for your industrial application. This 8-inch valve is designed with Double Offset and conforms to the API 609 standard. Its A995 5A body & disc and RPTFE seat ensure exceptional durability and performance. The bare shaft with ISO 5211 mounting makes it easy to install and operate. Purchase this 150 LB rated valve for reliable and efficient flow control in your operations.
Flanged High-Performance Butterfly Valve, Double Offset, API 609, 8 Inch, 150 LB, A995 5A body & Disc, RPTFE seat, bare shaft with ISO 5211 Mounting
Valve Description:
1862010 Double Offset Butterfly Valve 8TB1R5A
Design Standard: API 609 Cat B
Structure: Double Offset
Nominal size: 8 Inch
Nominal class: 150 LB
End Connection: Flanged-RF
Operation: Bare Stem, ISO 5211 Mounting
Body Material: ASTM A995 5A
Trim Material: A995 5A disc, RPTFE seat
Face to face: API 609
Test and inspection: API 598
Key Features: Long working life for frequent open/close (million cyclings), Low torque, Replaceable seat, Tight sealing, Excellent control characteristics
Product Range:
Body material: WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 48 Inch (DN50 - DN800)
Pressure range: Class 150 - 300 LB
End connection: Wafer, Lug, Flanged
Working temperature: -29℃ - +120℃
Operation: Lever, Gear
