Designed as secondary voltage resistance welding cable leads, Battery cables, Temporary power uses, Power supply applications not exceeding 600V AC.
CONSTRUCTION:
CONDUCTOR: 6 AWG- 4/0 AWG Stranded bare copper flexible, fully annealed, Class K, Bare-copper.
INSULATION: Chlorinated Polyethylene (CPE) Lead free
COLOR: Black
TEMPERATURE RANGE: -40°C to 90°C Dry, 90°C Wet
PHYSICAL PROPERTIES:
Oil and Water Resistant Non-Marking Jacket, Lightweight & Very Flexible at Low Temp.
ELECTRICAL PROPERTIES:
VOLTAGE RATING: 600V rms, Maximum
INDUSTRY APPROVALS: ASTM B-172, National Electrical Code 630, ROHS
