Chinese Designation: RV
International Designation: H03VV-F, H05VV-F
Cores: 2-7
Range of cross sections: 0.5sq mm-120 sq mm
Application: for switch control
Standard: ICE60027
Construction:
Conductor - Class 5 fine annealed copper wires
Insulation - PVC
Sheath - PVC
Color - on request
Max.Working Temperature: 70℃
Packing: 100 meter / Roll
