Teach-in board for cruise control

Functional features
1. Real and operable automotive electronic cruise system, fully display the composition of automotive electronic cruise system.
The operation of the accelerator pedal position sensor can realize the adjustment of throttle opening, which can truly show the working principle and working process of electronic throttle; Operate the cruise control switch and vehicle speed signal to set the cruise status, and the engine control unit can adjust the throttle opening, truly demonstrating the working process and working principle of the automotive electronic cruise system.
2. The teach-in board panel adopts 4mm thick high-grade aluminum-plastic panel with corrosion resistance, impact resistance, pollution resistance, fire prevention and moisture resistance, and the surface is sprayed with primer treatment by special process; The panel is printed with a color circuit diagram that never fades, and the surface is sprayed with varnish; Students can visually compare circuit diagrams and physical objects to understand and analyze the working principle of automotive electronic cruise system.
3. The detection terminal is installed on the panel of the teach pendant, which can directly detect the electrical signals of each circuit element of the cruise system, such as resistance, voltage, current, frequency signal, etc. on the panel.
4. The panel of the teach pendant board is equipped with fault indicator and diagnostic base, which can be connected to a special or general-purpose automobile decoder to read fault codes and clear fault codes and other self-diagnosis functions for cruise control units.
5. The panel part of the teaching board adopts 1.5mm cold plate stamping forming structure, which has a beautiful appearance; the bottom frame part adopts steel structure welding, the surface adopts spraying process, with self-locking caster device, and the base of the teaching board is equipped with a desktop of about 40cm, which is convenient for placing data, testing instruments, etc.
6. The teaching board works with ordinary 220V AC power supply, which is converted into 12V DC power supply by internal circuit voltage transformation rectification, without battery, reducing the trouble of charging, and 12V DC power supply has anti-short circuit function. c ...
