Get top-quality Integral Flanged China Gate Valve from leading manufacturers. Our valve is made with ASTM A182 F316, featuring 1 Inch size, DN25, 150 LB, PN20 pressure rating, and complies with API 602 and ASME B16.34 standards. Designed with a Bolted Bonnet, OS & Y, and Trim 12. RF Flanged Ends ensure a secure fit. Trust us for reliable, durable, and efficient gate valves for your industrial needs.
Valve Description:
1851024 API 602 Forged Gate Valve 1G1RF31612
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet, OS & Y
Nominal size: 1 Inch
Nominal class: 150 LB
Bore: Regular Bore
End Connection: RF-Flanged end
Operation: Handwheel
Body Material: ASTM A182 F316
Trim Material: ASTM A182 F316+STL.6
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Independent backseat, Fully guided solid wedge, Adjustable Packing Gland, Integral Flange
