Inner Race Groove Grinding Machine QMB125
product description
Inner race grinding machine with one-time clamping and processing of multiple BJ groove, 20-65 mm processing of groove diameter, which is suitable for the precision grinding of inner race. High precision, high efficiency, it can carry with truss or joint robot and automatical line.
Cnc machine Technical Parameters
|
ITEM |
QMB125 |
|
Max Clamping Diameter, mm |
Ø75 |
|
Max Workpiece Height, mm |
60 |
|
Groove Diameter Scope, mm |
Ø20-Ø65 |
|
DiameterOf Steel Ball Scope, mm |
Ø12.7-Ø22 |
