Performance and Characteristics：
The machine is a new type one that we adopt fast-development automatic control technology and then create and design It has the characteristics such as high technological content, novel structure, high efficiency, low noise, conveniently maintaining and mending. etc.
It is suitable or the packing of troche, capsule and electronic component of vocations such as pharmacy, electron and food etc. And it is also suit able for packing of nubby objects such as candy, etc. It has a good photophobic and sealed function.
It adopts PLC control. Its procedures such as filling, hot sealing, tangent printing batch code, cutting adjusting procedure, etc. can be randomly set. It can not be limited by common type machine’s machinery ranking gear, speed proportion. So the work will more convenient, the speed of packing will be high, the effect of the packing will be better.
Technical Parameters
|
Model |
DL-150 |
DL-200 |
|
Speed of roll (rollers/min) |
7-15 |
7-15 |
|
Capacity (pieces/hour) |
20000-60000 |
26000-80000 |
|
Max.packing width (mm) |
150 |
200 |
|
PVC for medicine(mm) |
0.05-0.1*150 |
0.08*200 |
|
AL-plsc combined filn(mm) |
0.08*150 |
0.08*200 |
|
Hole Dia. Of reel(mm) |
Ф40-45 |
Ф40-45 |
|
Electrical heating power(KW) |
2 |
3 |
|
Overall dimensions |
1450*600*1700 |
1450*800*1700 |
|
Weight（kg) |
600 |
800 |
