Table 1-1 hot chamber die casting machine technical parameters
HOT CHAMBER DIE-CASTING MACHINE SPECIFICATIONS
|
ITEM
project
|
UNIT
unit
|
KS38T
|
|
Clamping Force
clamping force
|
KN
|
380
|
|
Clamping stroke
Clamping Stroke
|
|
200
|
|
Ejector Force
top output
|
KN
|
30
|
|
Ejector Stroke
top of the stroke
|
|
50
|
|
Mould thickness
from Mold thickness
|
|
100-320
|
|
Moulding board size
template size
|
|
450 * 480
|
|
Lnner space between tiebbbar
Gelin column from
|
|
290 * 290
|
|
Gelin column diameter
Tiebar diameter
|
|
50
|
|
feed location shooting
Lnjection place
|
|
0-40
|
|
Lnjection force
shot material force
|
KN
|
45
|
|
Lnjection stroke
radio feed stroke
|
|
125
|
|
shoot feeding amount
Lnjection stroke
|
|
0.65/0.82/1.1
|
|
Hammer diameter
diameter hammer
|
|
35/40/45
|
|
Traverse stroke
trip from the mouth
|
|
150
|
|
working pressure
Working pressure
|
Mp
a
|
10
|
|
Driving Motor
motor power
|
KW
|
7.5
|
|
crucible capacity
Crucible Capability
|
L (kg / Zn)
|
50 (325)
|
|
Puel oll ;
fuel
|
kg / h
|
4
|
|
Electric cooker
furnace
|
kw
|
20
|
|
Fuel tank capacity
Oil box capability
|
L
|
200
|
|
Injection nozzle heating power nozzle heating tools
|
kw
|
2
|
|
Weight
Machine weight
|
kg
|
2800
|
|
The total size of the fuselage
Overall dimension
|
|
3100 * 1120 * 1600
|
